Cisco Short wavelength (1000BASE-SX) GBIC

Today: $367.58
Out of stock
  • Enter your e-mail address, we will notify you if it comes back in stock.

Cisco Short wavelength (1000BASE-SX) GBIC - 1 x 1000Base-SX

Technical Specifications

  • Description
  • General Information
  • Technical Information
  • Interfaces/Ports
  • Media & Performance
  • Environmental Conditions
  • Physical Characteristics
  • Miscellaneous

Cisco Short wavelength (1000BASE-SX) GBIC

Description
Description

Cisco's industry-standard Gigabit Interface Converter (GBIC) is a hot-swappable input/output device that plugs into a Gigabit Ethernet port/slot, linking the port with the fiber-optic network. GBICs can be used and interchanged on a wide variety of Cisco products and can be intermixed in combinations of IEEE 802.3z- compliant 1000BaseSX, 1000BaseLX/LH, or 1000BaseZX interfaces on a port-by-port basis. Furthermore, Cisco is offering a 1000BaseLX/LH interface that is fully compliant with the IEEE 802.3z 1000BaseLX standard, but has the ability to go up to 10 km over single-mode fiber, 5 km further than garden-variety 1000BaseLX interfaces. As additional capabilities are developed, these modules make it easy to upgrade to the latest interface technology, maximizing investment protection.

General Information
Manufacturer Cisco Systems, Inc
Manufacturer Part Number WS-G5484=
Manufacturer Website Address http://www.cisco.com
Brand Name Cisco
Product Name Short wavelength (1000BASE-SX) GBIC
Product Type GBIC
Technical Information
Application/Usage Data Networking
Interfaces/Ports
Interfaces/Ports 1 x 1000Base-SX LAN
Interfaces/Ports Details 1 x SC 1000Base-SX LAN
Media & Performance
Connectivity Media 50 µm Multi-mode Optical Fiber
Distance Supported 1804 ft 50.0 µm Optical Fiber, 902 ft 62.5 µm Optical Fiber
Data Transfer Rate 1 Gbps Gigabit Ethernet
Environmental Conditions
Temperature 32?F (0?C) to 122?F (50?C) Operating, -40?F (-40?C) to 185?F (85?C) Storage
Physical Characteristics
Dimensions 0.4" Height x 1.2" Width x 2.6" Depth
Weight (Approximate) 0.96 oz
Miscellaneous
Additional Information GBIC Channel Insertion Loss:
  • Transmitter output power (minimum/maximum): 0/-9.5 dBm
  • Receiver maximum input power: 0 dBm
  • Receiver sensitivity: -17 dBm
  • 50 micron MMF: 3.4 dB
  • 62.5 micron MMF: 3.2 dB
  • Contains a Class 1 laser of 850 nm for 1000BASE-SX (short-wavelength) applications

    Connector polishing:
  • The SX GBIC uses ball lenses and an air gap. A flat polish on the fiber-optic interface connectors is suggested
Compatibility
  • Catalyst 4000
  • Catalyst 5000
  • Catalyst 6000
Certifications & Standards
  • IEEE 802.3z

    Regulatory and Standards Compliance:
  • Safety - Laser Class I 21CFR1040
